Rigid PCB Antenna

Detailed Technical Specifications

Our factory's standard model rigid PCB antenna has undergone comprehensive laboratory testing and verification for all parameters, ensuring accurate and traceable specifications. It is designed to meet the wireless communication requirements of various civilian and industrial applications. The key specifications are listed below (customization and modifications are available):

Product Competitive Advantages Compared to Peers

Currently, ordinary low-end products on the market often have issues such as inaccurate impedance, significant signal attenuation, inconsistent batch parameters, and poor high-temperature resistance. As a professional China rigid PCB antenna manufacturer, our factory has carried out comprehensive upgrades in four key areas—process technology, material selection, testing, and customization—and offers significant advantages over competitors.

Installation and Usage Guide

Simple installation and flexible compatibility with no complicated debugging required. Three standard installation methods are available to meet the production requirements of different devices, ensuring a smooth and efficient installation process.

Surface-Mount Installation

Suitable for large-scale SMT production equipment, the antenna can be directly placed and soldered onto the designated position of the device motherboard using a pick-and-place machine, enabling automated assembly with high efficiency and consistency. During installation, avoid placing the antenna near interference sources such as batteries, metal shielding covers, or high-frequency chips. Maintain a clearance of at least 3 mm to ensure stable signal transmission.

Hand-Welded Installation

For small-batch prototypes, testing, and repair applications, manual soldering can be used to accurately align the antenna pads with the RF soldering points on the mainboard. Use low-temperature and quick soldering methods to prevent heat damage to the antenna circuit. After soldering, arrange the wiring properly to avoid excessive bending or compression.

Terminal Butt Joint Installation

The rigid PCB antenna with an IPEX connector can be directly connected to the RF socket on the device motherboard. It supports plug-and-play installation without soldering, allowing easy assembly and removal, making it ideal for prototype testing and small-batch equipment applications.

Product Selection Tips

Many customers may encounter difficulties when purchasing antennas. Incorrect selection can result in weak device signals, compatibility issues, and project delays. Based on years of industry experience, our factory has developed professional purchasing guidelines to help customers make accurate choices and avoid potential risks.

Match the Corresponding Frequency Band

Priority should be given to selecting antennas according to the device module's operating frequency. For 2.4G devices, choose a single-frequency 2.4G antenna; for dual-band devices, select a 2.4G+5.8G dual-band antenna. Incorrect frequency matching may lead to signal loss or unstable transmission.

Confirm the Equipment Installation Space

Select a standard-size or customized miniature antenna based on the available space inside the device. This helps avoid installation problems caused by oversized designs or insufficient performance caused by unsuitable antenna dimensions.

Consider the Operating Environment

For general civilian applications, standard models are recommended. For industrial environments with high temperatures or strong electromagnetic interference, select a reinforced rigid PCB antenna solution to ensure long-term stable operation.

Verify Parameter Accuracy

Pay close attention to key parameters such as VSWR, impedance, and gain. Avoid products with inaccurate specifications and prioritize suppliers that can provide actual measurement reports and reliable test data.

Choose a Reliable Source Manufacturer

Select a reputable antenna manufacturer that provides customization capabilities, quality verification, and after-sales support to ensure stable mass production and consistent product performance.

Why Choose Qianmu Communications?

With many years of experience in the wireless communications industry, Qianmu Communications is a China rigid PCB antenna manufacturer that has built long-term partnerships with customers worldwide. By leveraging four core strengths—technology, production capacity, quality, and service—we have become a trusted supplier for both domestic and international clients.

Professional Technical Team with Strong R&D Capabilities

We have an experienced RF engineering team specializing in antenna impedance tuning, frequency band optimization, and structural adaptation. Our experts can quickly solve signal challenges across different devices and provide customers with free antenna solution optimization and prototype debugging support.

Direct Supply from the Source Factory with Competitive Value

With standardized production facilities and automated equipment, we eliminate unnecessary middleman costs and provide significant price advantages for bulk orders. Meanwhile, we strictly control the defective product rate to help customers reduce after-sales costs.

Strong Customization Capabilities for Various Applications

We provide customized antenna solutions covering different frequency bands, sizes, structures, and performance requirements. With rapid prototyping and efficient mass production capabilities, we can meet the needs of niche devices and special operating environments.

Strict Quality Control and Full Product Traceability

Each product batch is supported by complete production records and testing data, enabling reliable traceability. Our product stability and consistency exceed general industry standards.

Comprehensive After-Sales Support for Reliable Service

We provide 24/7 technical consultation, inspection reports, and qualification documents with shipments. Our responsive after-sales service ensures customers receive continuous support throughout their projects.

FAQ

Q1: Can it support custom sizes and frequency bands?

A: Absolutely. As a professional antenna manufacturer, our factory provides comprehensive customization services. We can develop customized solutions based on your device's structural design, installation dimensions, required frequency bands, and gain specifications. Free solution proposals and sample production are available.

Q2: What causes poor signal after installation?

A: The most common reasons include improper installation, such as placing the antenna too close to metal components, power lines, or chip interference sources, or leaving insufficient clearance around the antenna. In addition, the antenna frequency band should be checked to ensure compatibility with the device module. Our factory provides professional tuning guidance to help quickly resolve signal issues.

Q3: What is the minimum order quantity? What is the delivery lead time?

A: There is no minimum order quantity for standard products. Small-batch customized orders and samples are also available. Standard orders can be delivered within the same day, while large-scale mass production usually takes 7–10 working days. Production schedules can be adjusted according to customer order priorities.

Q4: Which is better: rigid PCB antenna or a conventional stick antenna?

A: For compact embedded devices, rigid PCB antenna is usually the preferred choice due to its small size, hidden installation capability, high integration, and strong adaptability. For outdoor equipment requiring long-distance transmission, traditional stick antennas may be more suitable.
